CSF 7217 High-Performance Cooling Radiator for NISSAN Skyline GT-R (R32) 1989-1993
The RB26 engine found in the R32 GT-R is particularly known for its ability to produce significant horsepower while remaining reliable. However, with increased power comes a substantial increase in heat output. While the factory radiator does an adequate job, it's always best to have more robust protection.
CSF set out to engineer a premium radiator that would provide maximum cooling efficiency while also being built for longevity. As the R32 is a valuable collector's car, it makes sense to use the highest quality parts when restoring or modifying one. Featuring CNC-machined billet aluminum end tanks, hand-welded to a high-quality aluminum core, this radiator performs even better than it looks.
The 2-row, 42mm core not only increases the radiator's capacity but also improves its ability to dissipate heat. CSF's exclusive B-Tube technology increases heat dissipation by approximately 15% compared to standard oval-welded tubes. Additionally, the super-efficient multi-louvered fins maximize airflow through the radiator core for optimal performance. The increased number of cooling rows also enhances the overall efficiency of the radiator. More cooling tubes mean more surface area for the coolant heat to dissipate.
Each end tank is crafted from CNC-machined billet aluminum, providing incredible strength and durability. The CNC machining ensures incredible precision and uniformity. This results in perfect end tanks that mate flawlessly to the 42mm core. Hand TIG welding joins the tanks to the core, creating the most robust radiator on the market for the R32 Skyline.
Included with every radiator is a 1.4 bar high-pressure cap featuring a debossed CSF logo. High-pressure radiator caps raise the boiling point of the coolant. This allows the system to be protected from boiling over at higher operating temperatures. While the radiator is designed to protect the system from these temperatures, it's always beneficial to have extra protection for situations where the coolant gets too hot.
Application:
OEM Part Number:
Benefits
- 100% CNC Machined Billet Aluminum End Tanks
- 2-Row, 42mm Super-Duty Core in 2 Rows
- 75 CSF Exclusive B-Tube Technology Cooling Tubes
- 6.5mm Height Super-Efficient Multi-Louvered Fins for Maximum Surface Contact
- CNC Machined Mounting Pins and OEM Style Inlet/Outlet
- 1/8 NPT Temperature Sensor Port on Top End Tank
- Top Rank Logo Debossed on Top End Tank and Painted to Match Chassis
- 100% TIG Welded All Aluminum Construction
- 1.4 Bar High Pressure Radiator Cap with Debossed CSF Logo
- Plug-and-Play Installation Requires Absolutely No Modifications
- Individually Leak Tested and Pressure Tested
- Factory Fan Shroud Mounting Points
- 2-Year Limited Warranty
- Limited Production Run
- 1989-1994 Nissan R32 Skyline GT-R (incl. V-Spec & V-Spec II)
- 1989-1993 Nissan R32 Skyline GTS / GTS-t / GTS-4 / GTS-25
- 1989-1993 Nissan R32 Skyline GTE
- 1989-1993 Nissan R32 Skyline GXi
- 1991-1993 Nissan Skyline R32 Autech Version
- 1990 Nissan Skyline GT-R Nismo
- Nissan: 21410-04U01
Specifications
- Part number
- 7217
- Dimensions
- 75.438 mm × 56.388 mm × 15.24 mm
- Weight
- 8.709 kg
